Penetration Bitumen 40/50 | Bitumen 40/50

Product Overview

Penetration Bitumen 40/50 (also called bitumen 40/50, 40/50 pen bitumen or semi-hard paving grade bitumen) is a paving bitumen produced from the residue of vacuum distillation of crude oil. The grade name refers to its needle penetration at 25 °C of 40–50 dmm (tenths of a millimetre); its softening point is 52–60 °C and its specific gravity is 1.01–1.06.

It is harder than the general-purpose 60/70 grade, so it gives asphalt mixtures higher stiffness and better resistance to rutting under heavy traffic and high ambient temperatures. It is mainly used in highways, airport pavements and industrial roads, especially in hot climates, and as a base for blended and modified bitumens.

Pars Universal Bitumen (PUB-Ltd) supplies Penetration Bitumen 40/50 in new steel drums (150–180 kg net), bulk in tankers or bitutainers, and jumbo bags or polybags on request, with worldwide shipping. See the technical data sheet below or contact us for a free quote.

Penetration Bitumen 40/50 Technical Properties

Penetration Bitumen 40/50 is a semi-hard paving bitumen refined from selected crude oils. Its penetration at 25 °C is between 40 and 50 dmm and its softening point is 52–60 °C, which gives it high stiffness and good resistance to deformation at high temperatures. These properties make it well suited to high-traffic roads and paving projects in hot climates, where rutting resistance is essential.

Paving Bitumen 40/50 Typical Specifications:

Penetration Bitumen 40/50 is a semi-hard paving bitumen refined from selected crude oils. Its penetration at 25 °C is between 40 and 50 dmm and its softening point is 52–60 °C, which gives it high stiffness and good resistance to deformation at high temperatures. These properties make it well suited to high-traffic roads and paving projects in hot climates, where rutting resistance is essential.

  •

Pen Grade Bitumen 40/50 Applications

Penetration Bitumen 40/50 is used mainly in road construction and maintenance and in the production of hot mix asphalt. It is also used as a base for blended and modified bitumens.

- Urban and Intercity Highways – Used in dense traffic zones to improve surface longevity and load-bearing capacity.
- Airport Pavements & Industrial Zones – Provides stability and performance under heavy loads.
- Hot Climate Paving – Excellent resistance to rutting in areas with high ambient temperatures.
- Blending and Modification – Used in producing blended and modified bitumens for advanced asphalt formulations.

Hard Asphalt Binder 40/50 Packing

  • New Steel Drums (150–180 kg net)

  • Bulk in Tankers or Bitutainers

  • Jumbo Bags or Polybag Packaging (on request)

  • Custom Packing available for export and industrial use

FAQs About Bitumen 40/50

Q: What is penetration bitumen 40/50?
A: Penetration bitumen 40/50 is a semi-hard paving-grade bitumen with a needle penetration of 40–50 dmm at 25 °C and a softening point of 52–60 °C. It is used where higher stiffness and rutting resistance are needed than with 60/70.

Q: What is the difference between bitumen 40/50 and 60/70?
A: Bitumen 40/50 is harder (penetration 40–50 dmm versus 60–70 dmm) and has a higher softening point. It suits heavy traffic and hot climates, while 60/70 is the more general-purpose paving grade.

Q: What is the difference between bitumen 40/50 and 35/50?
A: Both are semi-hard paving grades with very similar hardness. The 35/50 grade is defined in the European standard EN 12591, while 40/50 is the grade listed in ASTM D946 and several national standards. Their softening point ranges are 50–58 °C and 52–60 °C respectively.

Q: Is bitumen 40/50 suitable for hot climates?
A: Yes. Its high stiffness and softening point give good resistance to rutting at high ambient temperatures.

Q: How is penetration bitumen 40/50 packed?
A: In new steel drums (150–180 kg net), in bulk (tankers or bitutainers), and in jumbo bags or polybags on request.

Penetration Bitumen 40/50

Technical Data Sheet

You can examine the technical details of Penetration Bitumen 40/50 product on the table. All the information you need about the product is included in the table.

Get a personalized quote for your specific requirements by writing to us at [email protected] or simply filling out the inquiry form here.

Last reviewed: November 2026

Property Test Method Unit Specification
Specific Gravity @ 25/25 °C ASTM D70/D70M – 1.01 – 1.06
Penetration @ 25 °C ASTM D5/D5M 0.1 mm 40 – 50
Softening Point (Ring & Ball) ASTM D36/D36M °C 52 – 60
Ductility @ 25 °C ASTM D113 cm 100 min
Loss on Heating ASTM D6/D6M % wt 0.2 max
Drop in Penetration after Heating ASTM D6/D6M & D5/D5M % 20 max
Flash Point (Cleveland Open Cup) ASTM D8254 °C 250 min
Solubility in Trichloroethylene or Toluene ASTM D2042 % wt 99.5 min
Matter Insoluble in Trichloroethylene or Toluene ASTM D2042 % wt 0.5 max
Spot Test AASHTO T 102 – Negative

Have any questions or concerns, or need more information about Hard Asphalt Binder 40/50? Reach out to our team at [email protected]
