Penetration Bitumen 35/50 | Bitumen 35/50

Product Overview

Penetration Bitumen 35/50 (also called bitumen 35/50, 35/50 pen bitumen or semi-hard paving grade bitumen) is a paving bitumen produced from the residue of vacuum distillation of crude oil. The grade name refers to its needle penetration at 25 °C of 35–50 dmm (tenths of a millimetre); its softening point is 50–58 °C and its specific gravity is 1.01–1.06.

It is harder than the general-purpose 50/70 grade, so it gives asphalt mixtures higher stiffness and better resistance to rutting under heavy traffic and in warm climates. It is mainly used as the binder in base and binder courses of hot mix asphalt for highways, airfields and heavy-load industrial pavements, and for blending with softer binders to produce intermediate grades.

Pars Universal Bitumen (PUB-Ltd) supplies Penetration Bitumen 35/50 in new steel drums (150–180 kg net), bulk in bitutainers or tankers, jumbo bags, and polybags or Kraft paper bags on request, with worldwide shipping. See the technical data sheet below or contact us for a free quote.

Penetration Bitumen 35/50 Technical Properties

Penetration Bitumen 35/50 is a semi-hard paving bitumen produced by vacuum distillation of crude oil. It is classified by its penetration of 35 to 50 dmm at 25 °C, which gives it a stiffer consistency than the general-purpose 50/70 grade, and has a softening point of 50–58 °C.

Typical Properties:

- Specific Gravity at 25/25 °C: 1.01–1.06
- Penetration at 25 °C: 35–50 dmm
- Softening Point: 50–58 °C
- Ductility at 25 °C: 100 cm min
- Flash Point: 250 °C min
- Solubility in TCE: 99.5% min

Penetration Bitumen 35/50 Applications

- Road Construction – Used as the binder in hot mix asphalt base and binder courses for highways, motorways and airfields, where a harder grade is required.
- Heavy-Traffic Pavements – Gives stiffness and resistance to rutting under heavy loads, especially in warm climates.
- Industrial Paving – Used in industrial zones and heavy-load pavements where stability and long service life are critical.
- Blending Material – Used to produce intermediate grades by blending with softer bitumen.

Pen Grade Bitumen 35/50 Packing

Pen Grade Bitumen 35/50 is available in various packaging forms depending on customer needs:

  • New steel drums (150–180 kg net)

  • Bulk in bitutainers or tankers

  • Polybag and craft paper bag (on request)

  • Jumbo bags (for large-volume orders)

FAQs About Bitumen 35/50

Q: What is penetration bitumen 35/50?
A: Penetration bitumen 35/50 is a semi-hard paving-grade bitumen with a needle penetration of 35–50 dmm at 25 °C and a softening point of 50–58 °C. It is used where higher stiffness and rutting resistance are needed than with 50/70.

Q: What is the difference between bitumen 35/50 and 50/70?
A: Bitumen 35/50 is harder (penetration 35–50 dmm versus 50–70 dmm) and has a higher softening point. It suits heavier traffic and warmer climates, while 50/70 is a more general-purpose paving grade.

Q: Where is bitumen 35/50 used?
A: It is mainly used in base and binder courses of hot mix asphalt for highways, airfields and heavy-load industrial pavements.

Q: How is penetration bitumen 35/50 packed?
A: In new steel drums (150–180 kg net), in bulk (bitutainers or tankers), in jumbo bags, and in polybags or Kraft paper bags on request.

Penetration Bitumen 35/50

Technical Data Sheet

You can examine the technical details of Penetration Bitumen 35/50 product on the table. All the information you need about the product is included in the table.

Get a personalized quote for your specific requirements by writing to us at [email protected] or simply filling out the inquiry form here.

Property Test Method Unit Specification
Specific Gravity @ 25/25 °C ASTM D70/D70M – 1.01 – 1.06
Penetration @ 25 °C ASTM D5/D5M 0.1 mm 35 – 50
Softening Point (Ring & Ball) ASTM D36/D36M °C 50 – 58
Ductility @ 25 °C ASTM D113 cm 100 min
Loss on Heating ASTM D6/D6M % wt 0.2 max
Drop in Penetration after Heating ASTM D6/D6M & D5/D5M % 20 max
Flash Point (Cleveland Open Cup) ASTM D8254 °C 250 min
Solubility in Trichloroethylene or Toluene ASTM D2042 % wt 99.5 min
Matter Insoluble in Trichloroethylene or Toluene ASTM D2042 % wt 0.5 max
Spot Test AASHTO T 102 – Negative
