penetration bitumen 40/60

Penetration Bitumen 40/60 | Bitumen 40/60

Product Overview

Penetration Bitumen 40/60 is a paving-grade bitumen with a needle penetration of 40–60 (0.1 mm at 25 °C) and a ring-and-ball softening point of 48–56 °C. According to the PUB-Ltd TDS, it has a specific gravity of 1.01–1.06 at 25/25 °C, a ductility of 100 cm minimum at 25 °C, a flash point of 250 °C minimum (Cleveland open cup), a solubility of 99.5% minimum and a negative spot test. Its penetration and softening point ranges follow the 40/60 grade of the EN 12591 paving-grade series.

It is produced by vacuum distillation of crude oil residue (vacuum bottom). Its stiffness suits asphalt for road base, binder and surface courses in warm climates and under heavy traffic.

PUB-Ltd supplies Penetration Bitumen 40/60 FOB Bandar Abbas in steel drums, jumbo bags or bulk. The TDS and MSDS are available on request.

Penetration Bitumen 40/60 Technical Properties

Penetration Bitumen 40/60 is a stiff paving-grade bitumen obtained by vacuum distillation of crude oil. Its penetration of 40–60 (0.1 mm at 25 °C) and softening point of 48–56 °C give it good stiffness at high service temperatures. It suits hot climates and heavily loaded roads, where it helps resist rutting.

Typical Specifications:

- Penetration at 25 °C: 40–60 (0.1 mm)
- Softening point: 48–56 °C
- Flash point (Cleveland open cup): 250 °C min
- Ductility at 25 °C: 100 cm min
- Loss on heating: 0.2 wt % max
- Solubility: 99.5 wt % min

The needle penetration of grade 40/60 is 40 to 60 decimillimetres (0.1 mm) at 25 °C, and its ring-and-ball softening point is 48 to 56 °C.

Paving Bitumen 40/60 Applications

Penetration Bitumen 40/60 is used as a binder in hot-mix asphalt for roads, airport runways and industrial pavements. It can also be blended with softer or modified binders to reach a required penetration.

- **High-Traffic Road Construction** – Used in highways, city streets and motorways that carry heavy, continuous traffic.
- **Asphalt Pavements in Warm Climates** – Its stiffness helps resist rutting and deformation at high pavement temperatures.
- **Runways and Industrial Yards** – Used in pavements that carry aircraft and heavy equipment loads.
- **Asphalt Mixes and Blends** – Can be blended with softer or modified binders to adjust penetration and performance.

Pen Grade Bitumen 40/60 Packing



Steel Drums (150–180 kg net)

Bulk Shipments in Tankers or Bitutainers

Jumbo Bags / Polybags (on request)

Custom Packing for project-specific needs

FAQs About Pen Grade Bitumen 40/60

Q: What is penetration bitumen 40/60?
A: Penetration bitumen 40/60 is a paving-grade bitumen with a needle penetration of 40–60 (0.1 mm at 25 °C) and a softening point of 48–56 °C. It is a stiff grade used in road asphalt.

Q: What are the main specifications of PUB-Ltd bitumen 40/60?
A: Specific gravity 1.01–1.06 at 25/25 °C, ductility 100 cm minimum at 25 °C, loss on heating 0.2% maximum, flash point 250 °C minimum, solubility 99.5% minimum and a negative spot test.

Q: How is bitumen 40/60 different from 50/70?
A: Grade 40/60 is harder: its penetration range is lower and its softening point range (48–56 °C) is higher than that of grade 50/70 (46–54 °C in EN 12591). It suits warmer climates and heavier traffic.

Q: Is bitumen the same as tar?
A: No. Tar is made from coal, while bitumen is a petroleum product made by vacuum distillation of crude oil. Paving bitumen is often called road bitumen or asphalt cement, but it is not tar.

Q: What packaging and shipping terms do you offer?
A: PUB-Ltd supplies bitumen 40/60 FOB Bandar Abbas in steel drums, jumbo bags or bulk.

Q: Can I get the TDS and MSDS?
A: Yes. The TDS and MSDS are available on request. Contact PUB-Ltd for the documents and a quotation.

Road Bitumen 40/60

Technical Data Sheet

You can examine the technical details of Penetration Bitumen 40/60 product on the table. All the information you need about the product is included in the table.

Get a personalized quote for your specific requirements by writing to us at [email protected] or simply filling out the inquiry form here.

Last reviewed: November 2026

No Property Unit Specification Test method
1 Specific gravity @ 25/25 °C – 1.01 – 1.06 ASTM D70
2 Penetration @ 25 °C (100 g, 5 s) 0.1 mm 40 – 60 ASTM D5/D5M, EN 1426
3 Softening point (ring and ball) °C 48 – 56 ASTM D36/D36M, EN 1427
4 Ductility @ 25 °C cm 100 min ASTM D113
5 Loss on heating wt % 0.2 max ASTM D6/D6M
6 Drop in penetration after heating % 20 max ASTM D6/D6M and D5/D5M
7 Flash point (Cleveland open cup) °C 250 min ASTM D92, EN ISO 2592
8 Solubility wt % 99.5 min ASTM D2042, EN 12592
9 Insoluble matter wt % 0.5 max ASTM D2042, EN 12592
10 Spot test – Negative AASHTO T 102

Have any questions or concerns, or need more information about Penetration Bitumen 40/60? Reach out to our team at [email protected]

You can contact our team for more detailed explanations. We are here to help you.

Our professional team offers you the most suitable products for your projects with quality and reliability.
