Penetration Bitumen 160/220

Product Overview

Penetration Bitumen 160/220 (also called bitumen 160/220, 160/220 pen bitumen or soft paving grade bitumen) is a very soft grade of paving bitumen produced from the residue of vacuum distillation of crude oil. The grade name refers to its needle penetration at 25 °C of 160–220 dmm (tenths of a millimetre); its softening point is 35–43 °C and its specific gravity is 1.01–1.06.

Its high penetration and low softening point give it excellent flexibility at low temperatures, which helps reduce thermal cracking in pavements. It is mainly used for road construction and maintenance in cold climates, for surface dressing and spray applications, and as the base bitumen for producing bitumen emulsions. Because it is much softer than common grades such as 60/70, it is not recommended for hot climates or heavy traffic.

Pars Universal Bitumen (PUB-Ltd) supplies Penetration Bitumen 160/220 in steel drums (150–180 kg net), bulk in tankers or bitutainers, and jumbo bags, with worldwide shipping. See the technical data sheet below or contact us for a free quote.

Penetration Bitumen 160/220 Technical Properties

Penetration Bitumen 160/220 is a very soft-grade bitumen with a penetration value between 160 and 220 dmm at 25°C. It is produced through the distillation of crude oil and is designed for use in cold climate conditions where high flexibility is required to prevent pavement cracking. Its low softening point allows it to perform well in freezing environments, maintaining elasticity even under thermal stress.

Typical Properties:

  • Penetration: 160–220 dmm

  • Softening Point: 35–43°C

  • Flash Point: >200°C

  • Ductility: >100 cm at 25°C

  • Solubility in TCE: >99.5%

Paving Bitumen 160/220 Applications

Paving Bitumen 160/220 is used as a raw material for insulating products, sealing and coating routes, repairing of the damaged road surfaces, road constructions, and as a spray bitumen. Because of its penetration degree, it can be used in special paints produced with bitumen, producing waterproof membranes, lubricants, and in many other product formulations.

  • Cold Climate Road Construction – Ideal for use in polar and sub-zero environments to prevent cracks due to contraction.

  • Low-Traffic Roads & Residential Areas – Suitable for roads where flexibility and surface preservation are more critical than load-bearing capacity.

  • Surface Dressing & Fog Seals – Used in road maintenance to rejuvenate and preserve existing asphalt surfaces.

  • Production of Bitumen Emulsions – Acts as a base for emulsified bitumen used in cold mix applications.

  • Flexible Asphalt Mixes – Applied where superior flexibility is needed, especially in frost-prone zones.

Pen Grade Bitumen 160/220 Packing

Pen Grade Bitumen 160/220 is available in various packaging forms depending on customer needs:

  • Steel Drums (150–180 kg net)

  • Bulk in Tankers or Bitutainers

  • Jumbo Bags / Polybags (on request)

  • Custom Packing available for project specifications

FAQs About Pen Grade Bitumen 160/220

Q: What is penetration bitumen 160/220?
A: Penetration bitumen 160/220 is a very soft paving-grade bitumen with a needle penetration of 160–220 dmm at 25 °C and a softening point of 35–43 °C. It is mainly used in cold-climate roads, surface dressing and emulsion production.

Q: When should bitumen 160/220 be used instead of 60/70?
A: Bitumen 160/220 is much softer and stays flexible at low temperatures, so it suits very cold climates and low-traffic roads. Harder grades such as 60/70 are preferred in warm climates and under heavier traffic.

Q: Can bitumen 160/220 be used to make bitumen emulsion?
A: Yes. Soft paving grades are commonly used as the base bitumen for bitumen emulsions.

Q: How is penetration bitumen 160/220 packed?
A: In steel drums (150–180 kg net), in bulk (tankers or bitutainers) and in jumbo bags on request.

Soft Asphalt Binder 160/220

Technical Data Sheet

You can examine the technical details of Penetration Bitumen 160/220 product on the table. All the information you need about the product is included in the table.

Last reviewed: November 2026

Get a personalized quote for your specific requirements by writing to us at [email protected] or simply filling out the inquiry form here.

Property Test Method Unit Specification
Specific Gravity @ 25/25 °C ASTM D70/D70M – 1.01 – 1.06
Penetration @ 25 °C ASTM D5/D5M 0.1 mm 160 – 220
Softening Point (Ring & Ball) ASTM D36/D36M °C 35 – 43
Ductility @ 25 °C ASTM D113 cm 100 min
Loss on Heating ASTM D6/D6M % wt 0.2 max
Drop in Penetration after Heating ASTM D6/D6M & D5/D5M % 20 max
Flash Point (Cleveland Open Cup) ASTM D8254 °C 250 min
Solubility in Trichloroethylene or Toluene ASTM D2042 % wt 99.5 min
Matter Insoluble in Trichloroethylene or Toluene ASTM D2042 % wt 0.2 max
Spot Test AASHTO T 102 – Negative

Have any questions or concerns, or need more information about Soft Asphalt Binder 160/220? Reach out to our team at [email protected]
